Telaio
telaio
C:62® Monocoque Advanced Twin Mold Technology, Aluminium 6061 T6 Rear Triangle, Efficient Trail Control, FSP 4-Link, Agile Trail Geometry, Boost 148, UDH™, Full Integrated Battery, Advanced Internal Cable Routing
misura
Size Split: 27.5: S // 29: M, L, XL
Sospensione
forcella ammortizzata
RockShox Psylo Silver RC Air, Tapered, 15x110mm, 150mm
ammortizzatore
RockShox Deluxe Select R, 230x60mm (27.5: 210x55mm), Rebound Adjust
viteria ammortizzatore
Front: 30x8mm, Rear: DU-Bushing 12.7mm
Sistema e-bike
motore
Bosch Drive Unit Performance Line CX max. 120Nm (BDU38)
Remoto
Bosch Mini Remote
batteria
Bosch PowerTube 800
display
Bosch Kiox 400C
caricatore
Bosch 2A
Trasmissione e freni
freni
Magura Louise, Front 4-Piston/Rear 4-Piston, Hydr. Disc Brake (203/203)
cambio
Shimano XT RD-M8200-SGS, ShadowPlus, 12-Speed
comandi cambio
Shimano Deore SL-M6210, Single Click
guarnitura
ACID MTB Hybrid Pro, 27.5: 36T // 29: 34T
pacco pignoni
Shimano Deore CS-M6100, 10-51T
catena
KMC e12
guidacatena
Reverse Flip-Guide E-Chain Guide, Direct Mount, I-Plate
Cockpit
serie sterzo
Acros AZF-675, ICR (Integrated Cable Routing), Top Zero-Stack 1 1/2″ (ZS 56mm), Bottom Zero-Stack 1 1/2″ (ZS 56mm), Fiber Inserts for Angle Adjustment, X-Connect Interface
Attacco Manubrio
CUBE Performance Stem E-MTB 35, FPI-Link
manubrio
CUBE Rise Trail Bar 35 VariGrip System
manopole
ACID Endure VariGrip System
Ruote
ruote
ACID SLX 30, 32/32 Spokes, 15x110mm/12x148mm, Tubeless Ready
copertoni
Schwalbe Nobby Nic, Performance, 2.6
Dotazione
sella
ACID Venec EMTB Trail 140
reggisella
CUBE Dropper Post, Handlebar Lever, Internal Cable Routing, 31.6mm
pedali
ACID PP MTB
Informazioni articolo
colore
oldgrey´n´black
peso
24,6 kg
Codice articolo
1103200
