Telaio
telaio
C:62® Monocoque Advanced Twin Mold Technology, Aluminium 6061 T6 Rear Triangle, Efficient Trail Control, FSP 4-Link, Agile Trail Geometry, Boost 148, UDH™, Full Integrated Battery, Advanced Internal Cable Routing
misura
Size Split: 27.5: S // 29: M, L, XL
Sospensione
forcella ammortizzata
Fox 36 Float Factory GRIPX, Tapered, 15x110mm, E-Bike Optimized, 150mm (S: 140mm)
ammortizzatore
Fox Float X Factory, 230x60mm (27.5: 210x55mm), Adjustable LSC/LSR w/ 2-Pos. Lever
viteria ammortizzatore
Front: 30x8mm, Rear: DU-Bushing 12.7mm
Sistema e-bike
motore
Bosch Drive Unit Performance Line CX max. 120Nm (BDU38)
Remoto
Bosch Mini Remote
batteria
Bosch PowerTube 800
display
Bosch Kiox 400C
caricatore
Bosch 4A
Tecnologia ABS
Bosch ABS Pro
Trasmissione e freni
freni
Shimano XTR BR-M9220, Hydr. Disc Brake w/ Front ABS (203/203)
cambio
Shimano XTR Di2 RD-M9260, 12-Speed, Electronic Shifting System
comandi cambio
Shimano XTR Di2 SW-M9250-I, Direct Attach
guarnitura
ACID MTB Hybrid Pro, 27.5: 36T // 29: 34T
pacco pignoni
Shimano XT CS-M8200, 10-51T
catena
Shimano CN-M8100
guidacatena
Reverse Flip-Guide E-Chain Guide, Direct Mount, I-Plate
Cockpit
serie sterzo
Acros AZF-675, ICR (Integrated Cable Routing), Top Zero-Stack 1 1/2″ (ZS 56mm), Bottom Zero-Stack 1 1/2″ (ZS 56mm), Fiber Inserts for Angle Adjustment, X-Connect Interface
Attacco Manubrio
CUBE Performance Stem E-MTB 35, FPI-Link
manubrio
Race Face ERA 35
manopole
ACID Endure
Ruote
ruote
Newmen Beskar 30 base/strong, 28/32 Spokes, 15x110mm/12x148mm, Tubeless Ready
copertone anteriore
Schwalbe Albert Trail Pro, Addix Soft, Kevlar, 2.5
copertone posteriore
Schwalbe Albert Gravity Pro, Addix Soft, Kevlar, 2.5
Dotazione
sella
ACID Venec EMTB Trail 140
reggisella
Fox Transfer Factory 31.6mm, Kashima Coated
pedali
ACID PP MTB
Informazioni articolo
colore
carbon´n´white
peso
24,3 kg
Codice articolo
1103800
