Telaio
telaio
Aluminum Superlite, Gravity Casting Technology, Efficient Comfort Control, FSP 4-Link, Agile Comfort Geometry, Boost 148, UDH™, Full Integrated Battery, Advanced Internal Cable Routing, Kickstand/Fender/Carrier Mounting Points, Integrated Seatclamp
misura
Size Split: 27.5: S // 29: M, L, XL
Sospensione
forcella ammortizzata
SR Suntour XCR36X 2CR Air, Tapered, 15x110mm, 120mm
ammortizzatore
SR Suntour EdgeX R 185×52.5mm, Rebound Adjust, Trunnion Mount
viteria ammortizzatore
Top: 54mm Trunnion Mount, Bottom: 22.2x8mm
Sistema e-bike
motore
Bosch Drive Unit Performance Line CX max. 120Nm (BDU38)
Remoto
Bosch Purion 200 with Integrated Display
batteria
Bosch PowerTube 800
caricatore
Bosch 2A
Trasmissione e freni
freni
Shimano BR-MT420, Hydr. Disc Brake (203/203)
cambio
Shimano Deore RD-M6200-SGS, ShadowPlus, 12-Speed
comandi cambio
Shimano Deore SL-M6210-IR, Direct Attach, Single Click
guarnitura
ACID MTB Hybrid Pro, 38T
pacco pignoni
Shimano Deore CS-M6200, 10-51T
catena
KMC e12
guidacatena
Reverse Flip-Guide E-Chain Guide, Direct Mount, I-Plate
Cockpit
serie sterzo
Acros AZF-1034, ICR (Integrated Cable Routing), Top Zero-Stack 1 1/2″ (ZS 56mm), Bottom Zero-Stack 1 1/2″ (ZS 56mm), X-Connect Interface
Attacco Manubrio
CUBE Performance Stem E-MTB 35, FPI-Link
manubrio
CUBE Rise Trail Bar 35
manopole
ACID Hybrid Perform
Ruote
ruote
ACID SLX 30, 32/32 Spokes, 15x110mm/12x148mm, Tubeless Ready
copertoni
Schwalbe Smart Sam, Active, 2.6
Dotazione
sella
ACID Venec EMTB Plus 145
reggisella
CUBE Dropper Post, Handlebar Lever, Internal Cable Routing, 31.6mm
pedali
ACID PP MTB
Informazioni articolo
colore
slabgrey´n´chrome
peso
26,8 kg
Codice articolo
1101200
