Descrizione

telaio
C:62® Monocoque Advanced Twin Mold Technology, Aluminium 6061 T6 Rear Triangle, Efficient Trail Control, FSP 4-Link, Agile Trail Geometry, Boost 148, UDH™, Full Integrated Battery, Advanced Internal Cable Routing

forcella ammortizzata
Fox 38 Float Rhythm, 2-Position Sweep-Adjust GRIP Damper, Tapered, 15x110mm, E-Bike Optimized, 170mm

ammortizzatore
Fox Float X Performance, 230x65mm, Adjustable LSR w/ 2-Pos. Lever

viteria ammortizzatore
Front: 30x8mm, Rear: DU-Bushing 12,7mm

motore
Bosch Drive Unit Performance Line CX 85Nm, Smart System

Remoto
Bosch System Control incl. Mini Remote

batteria
Bosch PowerTube 800

caricatore
Bosch 4A

freni
Shimano XT BR-M8120, Hydr. Disc Brake (203/203)

cambio
Shimano XT RD-M8100-SGS, ShadowPlus, 12-Speed

pacco pignoni
Shimano Deore CS-M6100, 10-51T

catena
KMC e12

guidacatena
Reverse Flip-Guide E-Chain Guide, Direct Mount, I-Plate

serie sterzo
ACROS AZF-675, ICR (Integrated Cable Routing), Top Zero-Stack 1 1/2″ (ZS 56mm), Bottom Zero-Stack 1 1/2″ (ZS 56mm), Fiber Inserts for Angle Adjustment, X-Connect Interface

Attacco Manubrio
CUBE Performance Stem E-MTB 35, FPI-Link

manubrio
CUBE Rise Trail Bar 35

manopole
ACID Disrupt, Soft Compound

ruote
Newmen Performance 30, 28/32 Spokes (Base/Strong), 15x110mm / 12x148mm, Tubeless Ready

copertone anteriore
Schwalbe Magic Mary, Addix Soft, Super Trail, Kevlar, 2.4

copertone posteriore
Schwalbe Tacky Chan, Addix Soft, Super Gravity, Kevlar, 2.4

sella
ACID Venec EMTB Trail 140

reggisella
CUBE Dropper Post, Handlebar Lever, Internal Cable Routing, 31.6mm

colore
blackline

peso
24,6 kg
