TELAIO
C:62® Monocoque Advanced Twin Mold Technology, Aluminium 6061 T6 Rear Triangle, Efficient Trail Control, FSP 4-Link, Agile Trail Geometry, Boost 148, UDH™, Full Integrated Battery, Advanced Internal Cable Routing
SOSPENSIONE
Forcella ammortizzata: Fox 36 Float Performance GRIP, Tapered, 15x110mm, E-Bike Optimized, 150mm
Ammortizzatore: Fox Float X Performance, 230x60mm (27.5: 210x55mm), Adjustable LSR w/ 2-Pos. Lever
Viteria ammortizzatore: Front: 30x8mm, Rear: DU-Bushing 12.7mm
SISTEMA E-BIKE
Motore: Bosch Drive Unit Performance Line CX max. 100Nm (BDU38)
Remoto: Bosch Mini Remote
Batteria: Bosch PowerTube 800
Display: Bosch Kiox 400C
Caricatore: Bosch 4A
TRASMISSIONE E FRENI
Freni: Sram Maven Bronze, Hydr. Disc Brake (200/200)
Cambio: Sram GX Eagle AXS™ Transmission, 12-Speed, Electronic Shifting System
Comandi cambio: Sram AXS™ Pod Controller
Guarnitura: ACID MTB Hybrid Carbon, 27.5: 36T // 29: 34T
Pacco pignoni: Sram XS-1275, 10-52T
Catena: Sram GX Eagle™ Transmission
Guidacatena: Reverse Flip-Guide E-Chain Guide, Direct Mount, I-Plate
Serie sterzo: ACROS AZF-675, ICR (Integrated Cable Routing), Top Zero-Stack 1 1/2″ (ZS 56mm), Bottom Zero-Stack 1 1/2″ (ZS 56mm), Fiber Inserts for Angle Adjustment, X-Connect Interface
Attacco Manubrio: CUBE Performance Stem E-MTB 35, FPI-Link
Manubrio: CUBE Rise Trail Bar 35
Manopole: ACID Disrupt
Ruote: Newmen Beskar 30 base/strong, 28/32 Spokes, 15x110mm/12x148mm, Tubeless Ready
Copertone anteriore: Conti Kryptotal Front, Enduro Soft, Tubeless Ready, 2.4
Copertone posteriore:Conti Kryptotal Rear, Downhill Soft, Tubeless Ready, 2.4
Dotazione
Sella: ACID Venec EMTB Trail 140
Reggisella: CUBE Dropper Post, Handlebar Lever, Internal Cable Routing, 31.6mm
Pedali: ACID PP MTB
Peso: 24,1 kg
