Descrizione
TRAVEL
Standard
170-180mm
GEOMETRY
Axle to Crown
585mm +/- 10mm at 170mm of travel
Axle to Crown (Extended)
585mm +/- 10mm at 180mm of travel
Fork Offset (Rake)
43mm
Max Rotor Size
220mm
STEERER TUBE
Size
Tapered 1.5”
Color
Black Anodized
CROWN
Color
Black
Material
Hollow Forged Aluminum
LOWERS
Color
Black (matt) / Ultraviolet (matt)
Dropout
15QR BOOST
Axle
Integrated Locking System (ILS): 15QR
STANCHIONS
Diameter (Ø)
35mm
Material
7075 Aluminum
Finish
Hard Anodized Black
ADJUSTMENTS
Rebound
18 Click Adjustment
Compression
High and Low Speed 12 Click Adjustment
Compression Tuning System
Gold and Blue valves included (other valves optional)
Neopos
Optional
Lockout
Crown mounted
Remote Cartridge Control
Optional
OTHER FEATURES
Damping
Drop-In Cartridge with Internal Floating Technology
Spring type
Air Spring
Negative spring
Steel (triple coil technology)
WEIGHT
Standard version
2.370g
