Telaio
- telaio Aluminum Superlite, Gravity Casting Technology, Agile Ride Geometry, Boost 148, UDH™, Full Integrated Battery, Advanced Internal Cable Routing, Kickstand/Fender/Carrier Mounting Points, Integrated Seatclamp
- misura Classic: Size Split: 27.5: S // 29: M L XL XXL
Sospensione
- forcella ammortizzata SR Suntour XCM32 NLO Coil, Tapered, 15x110mm, 120mm (27,5: 100mm)
Sistema e-bike
- motore Bosch Drive Unit Performance Line CX max. 120Nm (BDU38)
- Remoto Bosch Purion 200 w/ Integrated Display
- batteria Bosch PowerTube 600
- caricatore Bosch 2A
Trasmissione e freni
- freni Shimano BR-MT200, Hydr. Disc Brake (180)
- cambio Shimano Cues RD-U6000-GS, 10-Speed
- comandi cambio Shimano Cues SL-U6000, Rapidfire-Plus
- guarnitura ACID MTB Hybrid Pro, 38T
- pacco pignoni Shimano Cues CS-LG400, 11-48T
- guidacatena Reverse Flip-Guide E-Chain Guide, Direct Mount, I-Plate
Cockpit
- serie sterzo ACROS AZF-1034, ICR (Integrated Cable Routing), Top Zero-Stack 1 1/2″ (ZS 56mm), Bottom Zero-Stack 1 1/2″ (ZS 56mm)
- manubrio CUBE Rise Trail Bar 35
- Attacco Manubrio CUBE Performance Stem E-MTB 35, FPI-Link
- manopole ACID React Pro
Ruote
- cerchi CUBE EX25, 32H, Disc, Tubeless Ready
- mozzo anteriore CUBE Engineered By Newmen, 15mm, Boost, Centerlock
- mozzo posteriore CUBE Engineered By Newmen, 12mm, Boost, Centerlock
- copertoni Schwalbe Smart Sam, Active, 2.6
Dotazione
- sella ACID Sequence Pro 160
- reggisella CUBE Performance Post, 31.6mm
- pedali ACID PP MTB
Informazioni articolo
- colore blackline
- peso 24,2 kg
- Peso massimo di carico del sistema 140 kg
- Massimo peso di ciclista 110 kg
