TELAIO
Telaio Aluminium Superlite, Gravity Casting Technology, Agile Ride Geometry, Boost148, Fully Integrated Battery, Advanced Internal Cable Routing, 1.5 Headtube, Kickstand/Fender/Carrier Mounting Points
Fully integrated battery
Advanced Internal Cable Routing
Modular Battery Sistem
Agile Ride Geometry
Aluminium Superlite
X-connect
SOSPENSIONE
Forcella ammortizzata SR Suntour XCM34 NLO Coil, Tapered, 15x110mm, 100mm
SISTEMA E-BIKE
Motore Bosch Drive Unit Performance Line 75Nm (BDU34)
Remoto Bosch Purion 200 with Integrated Display
Batteria Bosch PowerTube 600
Caricatore Bosch 2A
TRASMISSIONE E FRENI
Freni
Shimano BR-MT200, Hydr. Disc Brake (180/180)
Cambio Shimano Cues RD-U4000-GS, 9-Speed
Comandi cambio Shimano Cues SL-U4010- Rapidfire-Plus
Guarnitura ACID MTB Hybrid Pro, 38T
Pacco pignoni Shimano Cues CS-LG300, 11-46T
Catena KMC eGlide
Guidacatena Reverse Flip-Guide E-Chain Guide, Direct Mount, I-Plate
Cockpit
Serie sterzo ACROS AZF-1034, ICR (Integrated Cable Routing), Top Zero-Stack 1 1/2″ (ZS 56mm), Bottom Zero-Stack 1 1/2″ (ZS 56mm), X-Connect Interface
Attacco Manubrio CUBE Performance Stem E-MTB 35, FPI-Link
Manubrio CUBE Rise Trail Bar 35
Monopole ACID Hybrid Perform
RUOTE
Route ACID Pro 30, 32/32 Spokes, 15x110mm/12x148mm, Tubeless Ready
Copertoni Schwalbe Smart Sam, Active, 2.6
DOTAZIONE
Sella ACID Sequence 160
Reggisella CUBE Performance Post, 31.6mm
Pedali ACID PP Trekking
INFORMAZIONI ARTICOLO
Colore electricblue´n´dazzle
Peso 25,9 kg
